Dimensions
LMV-X8: 8L x 4.75W x 1.75D
LMV-X16: 16L x 4.75W x 1.75D
LMV-X24: 24L x 4.75W x 1.75D
LMV-X36: 36L x 4.75W x 1.75D

Listing & Certification
UL Certified for Dry Location, Standard 1598

Features
• Standard profile design for easy installation
• Mounting accessories: Nm/Bx connectors | Mounting screws
•  Wiring knockouts available for wiring flexibility | Located on top and rear panels
•  Provided with bi-pins lamps | Model number noted in spec sheet
•  Hi-low rocker switch included
•  Heavy-gauge steel housing
• Clear prismatic glass
