Lumivert Lighting

LED-RCD Series

SKU LED_RCD5_11W_30
  • LED-RCD Series

Lumivert Lighting

LED-RCD Series

SKU LED_RCD5_11W_30

Dimensions
LED-RCD5/11/30: 4.75Ø x 0.5H
LED-RCD7/14W/30: 7Ø x 0.5H

Listings & Certifications
• C-ETL (Wet Location Rated) | CSA STD. C222.2 NO. 250.0 | Conforms to UL Standard 1598
• Type IC Rated
• Energy Star Certified

Electrical
• Line voltage operation: 120V|60Hz
• Installation accessories included: [2] dry wall screws, [2] dry wall anchors, [1] plastic wire protector & strain relief, [3] wire nuts
• Driver box separate from fixture, [2] knockouts included for line voltage power supply
• Fixture connector wire: 22AWG 80° 300V [Male type, UL Recognized component]
• Driver connector wire: 22AWG 80° 300V [Female type, UL Recognized component]

Features
• Low profile (without driver included) | Flush with ceiling after installation
• Extruded aluminum housing, powder-coated finishes
• Edge-lit lighting eliminates hot spots, creates even lighting distribution
• Frosted polycarbonate diffuser
• Dimmable (Tri-Ac)

 (See Spec Sheet for Driver Specifications)
